Features
-
Comply with PROFINET V2.4;
-
Comply with V2.43 GSDML;
-
Support RT data communication;
-
Support up to 1440 bytes input and 1440 bytes output;
-
Integrated dual-port switch;
-
Provide 16 card slots;
-
CANopen master station supports the Baud rate 10k~1M;
-
Manage up to 127 CANOpen slave devices;
-
CANopen master station supports SDO mechanism, initializes and configures slave station dictionary;
-
CANopen master station supports 128 groups of TPDOs and 128 groups of RPDOs;
-
CANopen master station supports synchronous signal mechanism;
-
CANopen master station supports heartbeat management mechanism.
