E2000 On-line Power Quality Monitoring Device

The E2000 is an on-line power quality monitoring device, which is developed by ZLG ZHIYUAN Electronics after long-term market research. It is specialized for enterprise-level users, and mainly used in large high energy-consuming enterprises, energy management, communication center, research and testing institutions and other industries. The E2000 is featured with compact size and high cost performance, and supports multiple communication protocols.With its accurate market positioning as well as mature and stable performance, E2000 is quickly recognized by the market and widely used for enterprise-level powerquality monitoring and analysis.

Learn more about parameters>

E2000 on-line power quality monitoring device

Basic parameters:

Mechanical specificationsDimensions(mm)144(width)×144(height)×196(length)mm
WeightAbout 2.5kg
DisplaySize5 inches
开关量输入2路继电器输出,触电负载(阻性:AC250V 8A),切换电压(400VAC/300VDC)

输入参数 :




环境可靠性 :

标准GB/T 2423.1-2008低温
GB/T 2423.2-2008高温
GB/T 2423.4-2008交变湿热
GB/T 2423.5-1995冲击
GB/T 2423.10-2008振动
GB/T 2423.22-2002温度变化

电磁兼容性 :

标准等级4:GB/T 17626.2-2006静电放电抗扰度
等级3:GB/T 17626.3-2006射频电磁场辐射抗扰度
等级3:GB/T 17626.4-2006电快速瞬变脉冲群抗扰度
等级3:GB/T 17626.5-2008浪涌(冲击)抗扰度
等级3:GB/T 17626.8-2006工频磁场抗扰度
等级3:GB/T 17626.9-1998脉冲磁场抗扰度
等级3:GB/T 17626.12-1998振荡波抗扰度

Voltage fluctuation and fault waveform recording

Capture all waveforms of voltage and current channels and analyze the interference source when the power grid is abnormal. When the harmonic distortion rate, voltage RMS and voltage unbalance exceed their limits, the voltage waveform and fault waveform recording are started to provide accurate data for the power quality management of power grid.

Harmonics analysis

Harmonics up to 63th order, interharmonics up to 50th and higher frequency harmonics of 2k~9kHz can be analyzed, which meets the harmonics testing requirements of public power grid specified in the GB/T 14549 and IEC 61000-4-7 standards.

Event alarm monitoring

The E2000 can detect power transient and steady-state events. The events are listed in the descending order, and the most recent event is placed in the top row. Users can position the cursor on the event list to view events by page. Furthermore, the event list can also be queried by date, therefore users can quickly and correctly locate the power quality problem by viewing past events.

Time Calibration

There are multiple time calibration methods, including SNTP, B code and PPS.

Multi-standard Protocol

Multiple communication protocols are supported, including Modbus (485/TCP) and IEC103.

Support for standardized data formats

It supports the PQDIF common standard data exchange format specified in IEEE 1159 and the IEEE Comtrade transient data exchange format for power systems.
