Features

• Comply with PROFINET V2.4;

• Comply with V2.43 GSDML;

• Support RT data communication;

• Support up to 1440 bytes input and 1440 bytes output;

• Integrated dual-port switch;

• Provide 16 card slots;

• Support setting parameters such as CAN type, CAN FD standard and CAN FD acceleration;

• CAN messaging supports multiple trigger modes such as cycle, state change and single sending;

• CAN messaging supports multiple data sources;

• Support sending and receiving messages in the form of full frame and byte;

• Support standard frames, extended frames and remote frames;

• With the user-defined sending mode, it can accurately customize and send CAN or CAN FD messages.
